SPECIALTY OVERHEAD DOORS

SPECIALTY PRODUCTS & ACCESSORIES

Pass Doors, Breakaway Bottom Doors, Dock Seals, and Chain Link and Security Screen Doors

Pass doors, breakaway bottom doors, dock seals, security chain link and screen doors.

Pass Doors

Pass doors are ideal in applications where space is too limited for the installation of a standard entry door. They conserve energy by allowing building access via a smaller opening versus the entire sectional door, this minimizes wear and tear on the door as well saves electric operator cycles. In inclimate weather, the heat or cold distribution between inside and outside of the building is minimized, conserving additional energy costs.

Available On 3720, 3722, 3724, 3200 and 3220 insulated models as well as 520 and 524 series non-insulated models



Break-away Bottom Sections

Break-away bottom sections will release from the track and swing up to a full 45 degree angle inward or outward, preventing further damage to the door.

Available On 3724, 3722, 3720, 3718, 3717, 3220, and 3200 models as well as all 520 series and all 524 series.



Dock Seals

Dock seals and shelters provide protection from the weather for your dock and personnel in almost every application. They seal loading docks against changes in the environment that can cost you time and money.

DS100 Compressible Foam Dock Seal
DS140 Adjustable Head Curtain Dock Seal
DS200 Rigid Dock Shelter

Features - Pass Door

welded aluminum frame - pass door Welded aluminum frame with shiplap design affords added strength and durability while providing a weather-tight door seal. Rain cap feature protects door entrance against accumulated water during rain showers.
geared hinge - pass door Geared hinge ensures smooth operation and enhances longevity of the pass door.
closer - pass door Commercial door closer ensures safe and quiet closure.
continuous boxed channel Continuous boxed channel bottom rail adds additional strength against wind and horizontal deflection.

Features - Break-away Bottom Section - View Video

  Clopay's Break-Away Bottom Section releases from the track and will swing up to a full 90 degree angle inward or 45 degrees outward, preventing further damage to the door.
  Bottom section snaps back into place in less than a minute.
  Inside of section has fiberglass protective panel to prevent damage to the door.
  Optional inside slide lock provides additional security. Padlock may be applied.
 Specifications:
  • Doors must have at least 24" of hi-lift.
  • 36" of headroom required.
  • Not compatible with door drop safety device/bottom brackets.
  • Not compatible with doors requiring a double torsion shaft
  •  Warranty: 1 Year Limited Construction



    Features - DS100/DS140

    Pad Design: High density polyurethane foam bonded to quality treated wood framing
    22 oz, 40 oz or 50 oz vinyl-coated polyester fabric

    24" high head curtain with 24" splits and hook & loop fasteners (DSI40 only)
    Full length 3" wide yellow guide stripe on side panels
    Nylon mesh breather panels on side and head pads

    Side and top seals available with beveled edges
    Colors: Standard color is black. Optional brown, blue green (50 oz vinyl available black only)
    Hardware: Rust-resistant mounting hardware
    Warranty: 1 year

    Features - DS200

    Pad Design: Pressure treated wood framing with translucent fiberglass top and 32 oz vinyl sides
    40 oz vinyl-coated fabric top and side face curtains mounted over a rigid frame
    Head curtain with vinyl-coated wear pleats at each end; sloped header to provide drainage; exterior frame corners trimmed with aluminum angle
    PVC bottom panels with highly visible yellow guide stripe
    Colors: Standard color is black. Optional brown, blue green (50 oz vinyl available black only)
    Guards: Two 6" steel channel guards to support and protect frame
    Hardware: Rust-resistant mounting hardware
    Warranty: 1 year
    ModelsBIMShop DrawingSpecificationLiterature(PDF)Instruction Manual(PDF)Warranty
    Aluminum — Polycarbonate 2 inch x 2 inch
    Model 950 DWG IconDXF IconPDF IconTXT Icon950Info.pdfInstallation ManualSupplemental Installation
    Dock Seals and Shelters
    Models DS100 PDF IconPDF IconPDF IconTXT IconModel DS100, DS140, DS200Installation ManualSupplemental Installation
    Models DS140 PDF IconPDF IconPDF IconTXT IconModel DS100, DS140, DS200Installation ManualSupplemental Installation
    Models DS200 PDF IconPDF IconPDF IconTXT IconModel DS100, DS140, DS200Installation ManualSupplemental Installation


    Click on appropriate icon to download
    To use the Spec Wizard, click here

    (What is Spec Wizard?)

    SpecWizard



    Collection Series Model/Design Door/Panel Style Max Width Max Height Construction/Material Colors
