AlarmGard Conceal
Seamlessly blend maximum fire safety with minimalist design. The AlarmGard® Conceal Operator is a low-profile solution for counter fire doors.
Seamlessly blend maximum fire safety with minimalist design. The AlarmGard® Conceal Operator is a low-profile solution for counter fire doors, increasing your usable space by 34%. Its sleek, concealed engineering is perfect for pharmacies, service counters, and any application where style and safety are paramount.
Our operator's superior, UL325-listed engineering delivers unmatched power and reliability. By utilizing a compact, chain-driven sprocket mounted at the front of the hood, it provides a space-saving solution that significantly outperforms traditional tube motors.
Peace of mind comes standard. The AlarmGard® Conceal operator ensures true failsafe operation with a standard battery backup for uninterrupted performance, even during a power outage. The motor's unique placement allows for effortless maintenance without removing the barrel, and simple plug-and-play connections make installation seamless.
Counter Fire Door
CERC10
CERC11 (SmokeShield®)
Input Voltage: 120 VAC/60Hz*
Phase: 1
Duty: up to 20 cycles/hour
*Other voltages and phases may be available with extended lead-time. Please contact factory
Counter fire door openings from 2'-7' wide, up to 120 square feet.
Model
BIM
Shop Drawing
Specs
Installation Manual
Warranty
BIM
-Shop Drawing
-Specifications
-Installation Manual
-Warranty
-Learn more about AlarmGard Coneal
